Product Details:
Payment & Shipping Terms:
|
Place Of Origin: | Guangdong, China | Brand Name: | JINDUN |
---|---|---|---|
Model Number: | 6N4A7028LCD | Detecting Tunnel: | Width 400mm* Height 100mm |
Belt Height From Ground: | 670mm ( Customized) | Language: | Chineses-English By Default |
Detecting Method: | Magnetic Field Induction | Sensitivity Degree: | 10 Degrees |
Alarm Mode: | Flap Reject, Sound And Light Alarm, Belt-stop | Conveyor Speed: | Fixed Speed 28m/min Or Adjustable 15-30m/min |
Input Power/ Voltage: | Single-phase 220VAC Or 110VAC 200W | Construction Material: | 304 SUS ( 316 SUS Available) |
Machine Weight: | 140kg |
Diameter
|
Φ35mm
|
Precision
|
Iron φ0.4mm
|
|
Copper φ0.5mm
|
|
SUS φ0.8mm
|
Detecting Weight
|
300-400KG/Hr
|
Detection Method
|
Electromagnetic Wave Detection Technology
|
Alarm Mode
|
Sound and Light Alarm with auto rejection
|
Elimination time
|
0.3-5seconds ( adjustable)
|
Gas Consumption
|
0.4 Liters Per Separation
|
Gas Input Source
|
0.3~0.5MBar
|
Output Signal Terminal
|
Counting signal, Reject signal
|
Frame Material
|
Paint
|
Input voltage /power
|
Single-phase AC200V 50Hz/100W
|
Operating Temperature
|
-10~+50ºC
|
Dimensions of the main part
|
Length 300*Width 400* Height 440(mm)
|
