Screen Display Weigher High Accuracy Fruit Fish Weight Sorting Machine

Screen Display Weigher High Accuracy Fruit Fish Weight Sorting Machine

large.img.alt
small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt

Large Image :  Screen Display Weigher High Accuracy Fruit Fish Weight Sorting Machine Get Best Price

Product Details:
Place of Origin: Guangdong, China
Brand Name: JINDUN
Model Number: JD-520
Payment & Shipping Terms:
Minimum Order Quantity: 1 Unit
Price: $10,000.00(1 - 2 Units) $9,280.00(3 - 9 Units) $8,570.00(10 - 99 Units) $7,850.00(>=100 Units)
Packaging Details: Wooden case
Supply Ability: 50 Unit/Units per Month
Detailed Product Description
Place Of Origin: Guangdong, China Brand Name: JINDUN
Model Number: JD-520 Display Type: 10.1 Inch Color TFT Touch Display
Touch Screen: 10.1 Inch Color TFT Touch Display Weighing Range: 5~1000g
Minimum Scale: 0.1g Sorting Accuracy: ± 0.2g~±1g
Weighing Section Size: L 400mm * W 220mm Belt Height From Ground: 680mm~750mm(Customized Height)
Sorting Method: 6 Outputs Sorting Material. Surface: 304 Stainless Steel Surface Polishing
Language: Chinese / English (more Languages Can Be Customized) Input Voltage / Power: Single Phase AC220V 50Hz/300W

Large LCD touch screen display automatic check weigher high accuracy fruit fish weight sorting machine

Product Description



Touch Screen 10.1 inch color TFT touch display
Weighing range 5~1000g
Minimum scale 0.1g
Sorting accuracy ± 0.2g~±1g
Detection object size L (mm):1~300
W(mm):1~200
H (mm):1~100
Weighing section size L 400mm * W 220mm
Belt height from ground 680mm~750mm(Customized Height)
Conveyor belt speed 20m / min fixed speed or 15-30m / min adjustable speed (speed can be customized)
Sorting Method 6 outputs Sorting
Material. Surface 304 stainless steel surface polishing
Language Chinese / English (more languages can be customized)
Input voltage / power Single Phase AC220V 50Hz/300W
Machine Weight 200Kg
Machine Size L2200mm*W 685mm *H 1335mm



Large LCD touch screen display automatic check weigher high accuracy fruit fish weight sorting machineLarge LCD touch screen display automatic check weigher high accuracy fruit fish weight sorting machineLarge LCD touch screen display automatic check weigher high accuracy fruit fish weight sorting machineLarge LCD touch screen display automatic check weigher high accuracy fruit fish weight sorting machineLarge LCD touch screen display automatic check weigher high accuracy fruit fish weight sorting machineLarge LCD touch screen display automatic check weigher high accuracy fruit fish weight sorting machine



Features:

1. EASY.
Large LCD touch screen display, Chinese and English interface, Language customized.



2. PRECISON.
High-precision sensor with high detection accuracy and fast detection speed.



3. REAL TIME.
The graph shows the statistical distribution of the sorting results and grasps the sorting dynamics in real time.



4. MEMORY.
100 kinds of product sorting parameters can be preset, and different products can be quickly switched.



5. AUTO-LEARN.
High-speed and high-precision digital filtering algorithm, data filtering parameters, automatic learning.



6. INTELLIGENT.
Dynamic zero tracking, including zero tracking when the equipment is continuously running, can automatically correct the weight value.



7. RELIABILITY.
Variable frequency motor drive, effectively improve the stability of equipment operation.



8. DATA.
Preset data transmission interface, can set or export product sorting parameters via USB.



9.ACCURACY.
The photoelectric check weighing trigger method is adopted to effectively improve the accuracy of the equipment.



10. REMOVE.
Multiple removal methods are optional, which can remove overweight or underweight products.

Company Information

JINDUN- we are innovative factory who focus on detect and inspection technology. Offer flexible solutions for global customer.
JINDUN manufactures quality control equipment that inspects and detect. We keep your products safe & standard, and protect your brands! JINDUN-DETECT AND INSPECTION TECHNOLOGY FOR Safety CONTROL



JINDUN-we are your reliable partner in infrared temperature & disinfection, quality control and security inspection! Based on Dongguan, a major manufacturing hub in China, Jindun is a global manufacturer,principally offer Infrared and disinfection Series (Infrared temperature, Full Body Disinfection)Quality Control Series (Metal Detector, Checkweigher, X-ray inspection) ,Security Series Product.



We have been providing our customers with customized machines to their quality control and security needs for more than 17 years.



CE-certified products, our reputation is based on consistent quality and advanced technology, the result of continuous and far-reaching research and development. Rigorous quality standards ensure that we meet customer specifications each time, every time.

Large LCD touch screen display automatic check weigher high accuracy fruit fish weight sorting machineLarge LCD touch screen display automatic check weigher high accuracy fruit fish weight sorting machine
