Product Details:
Payment & Shipping Terms:
|
Warranty: | 1 Year, 1 Year | Type: | Metal Detector, Automation |
---|---|---|---|
Customized Support: | OEM, ODM | Place Of Origin: | Guangdong, China |
Brand Name: | JINDUN | Model Number: | JD-905 |
Product Name: | Detector Machine Stainless Steel Metal Separator | Material Processed: | Stainless Steel |
Plastic Type: | PVC | Screw: | Double-Screw |
Transport Package: | Wooden Case | Dimensions Of The Main Part: | Length 300*Width 400* Height 440(mm) |
Key Words: | Metal Separator | Certification: | CE |
Diameter
|
Φ35mm
|
Precision
|
Iron φ0.4mm
Copper φ0.5mm SUS φ0.8mm |
Detecting Weight
|
300-400KG/Hr
|
Detection Method
|
Electromagnetic Wave Detection Technology
|
Alarm Mode
|
Sound and Light Alarm with auto rejection
|
Elimination time
|
0.3-5seconds ( adjustable)
|
Gas Consumption
|
0.4 Liters Per Separation
|
Gas Input Source
|
0.3~0.5MBar
|
Output Signal Terminal
|
Counting signal, Reject signal
|
Frame Material
|
Paint
|
Input voltage /power
|
Single-phase AC200V 50Hz/100W
|
Operating Temperature
|
-10~+50ºC
|
Dimensions of the main part
|
Length 300*Width 400* Height 440(mm)
|
